GLI-WLLC – Linear Led Wrap Light

Wraparound Linear Light C

The GLI-WLLC Wraparound Linear Light C is a rugged and high-efficiency linear LED fixture, designed for offices, classrooms, hallways, parkades, stairwells, and service areas. With an optional occupancy sensor and battery backup, it provides smart energy-saving lighting while maintaining high-lumen output and durability.

Certifications:

https://resolvelighting.ca/wp-content/uploads/2025/04/Screenshot-2025-03-30-191810.png
  • Specifications
  • Add to Project

Lighting:

Cost-efficient utilitarian LED wrap light for commercial applications
Available wattage and lumen output:
2FT Model: 25W (2250LM, 90LM/W), 4FT Model: 40W (3600LM, 90LM/W)
Selectable CCT Options:
3000K, 3500K, 4000K, 4500K, 5000K
Excellent color rendering with CRI 82

Installation:

Mounting Options:
Surface-mounted installation, Suspended installation via chain mount
Available in 2FT and 4FT lengths

Electrical:

Voltage Compatibility:
120V
Dimming Control:
0-10V dimming and DALI control
Optional Features:
Battery backup for emergency lighting compliance, Occupancy sensor for automated energy savings

Details & Accessories:

White enamel finish for durability and aesthetics
Milky or clear lens options available
Operating temperature:
-20°C to +40°C

Certifications:

cULus Listed, Damp location rated

Warranty & Lifespans:

5-year limited warranty, 50,000-hour rated lifespan

Resources

Technical Specs

file View
GLI-WLLC-Wraparound-Linear-Light-C.pdf
download

Installation Manual

file View
GLI-WLLC_Wraparound-Linear-Light-C-Installation-Manual.pdf
download

.IES Files

file View
GLI-WLLC-2-25W-5CCT.zip
download
file View
GLI-WLLC-4-40W-5CCT.zip
download
