GLI-VDLB – Versatile Downlight B

Versatile Downlight B

The GLI-VDLB Versatile Downlight B is a high-performance, energy-efficient recessed downlight designed for commercial, residential, and hospitality applications. Featuring field-selectable wattage and CCT, an integrated wiring junction box, and a remote driver, this fixture ensures quick installation and reliable illumination.

Certifications:

https://resolvelighting.ca/wp-content/uploads/2025/03/Screenshot-2025-03-24-125931.png
  • Specifications
  • Add to Project

Lighting:

Sizes:
4inches, 6 inches, 8 inches and 10 inches
arrow up

Spun aluminum reflector with haze finish and white trim ring
Selectable CCT options:
Individual: 2700K, 3000K, 3500K, 4000K, 5000K; 3CCT: 3000K, 4000K, 5000K
Beam Angles:
50°/70° (4” and 6”), 40°/60° (8” and 10”)
Luminous Efficacy:
90LM/W - 100LM/W
Lumen Output:
4” Model: 900LM - 1775LM (10W, 15W, 20W); 6” Model: 2100LM - 3800LM (20W, 30W, 40W); 8” Model: 3900LM - 5700LM (40W, 50W, 60W); 10” Model: 3900LM - 5700LM (40W, 50W, 60W)

Installation:

Mounting options:
Spring clips ensure a secure, flush fit with the ceiling
Remote driver enhances flexibility for tight ceiling spaces
Integrated wiring junction box reduces installation costs and time

Electrical:

Selectable Wattage Options:
4” Model: 10W, 15W, 20W; 6” Model: 20W, 30W, 40W; 8” Model: 40W, 50W, 60W; 10” Model: 40W, 50W, 60W
Voltage Compatibility:
120V-277V
Dimming Options:
1-10V dimmable
High Power Factor:
≥0.9

Details & Accessories:

Aluminum housing acts as a heat sink, maximizing lifespan
No UV/IR emissions, environmentally friendly
Available Accessories:
T-grid ceiling plate, Joist ceiling plate, New construction frame

Certifications:

cETLus Classified
Wet Location Rated

Warranty & Lifespans:

5-year
Estimated lifespan of over 50,000 hours

Resources

Spec Sheet

file View
GLI-VDLB-Versatile-Downlight-B.pdf
download

Install Manual

file View
GLI-VDLB-Installation-Manual.pdf
download

.IES Files

file View
GLI-VDLB-4-10W-5CCT-50Degree.zip
download
file View
GLI-VDLB-4-15W-5CCT-50Degree.zip
download
file View
GLI-VDLB-4-20W-5CCT-50Degree.zip
download
file View
GLI-VDLB-4-10W-5CCT-70Degree.zip
download
file View
GLI-VDLB-4-15W-5CCT-70Degree.zip
download
file View
GLI-VDLB-4-20W-5CCT-70Degree.zip
download
file View
GLI-VDLB-6-20W-5CCT-50Degree.zip
download
file View
GLI-VDLB-6-30W-5CCT-50Degree.zip
download
file View
GLI-VDLB-6-40W-5CCT-50Degree.zip
download
file View
GLI-VDLB-6-30W-5CCT-70Degree.zip
download
file View
GLI-VDLB-6-40W-5CCT-70Degree.zip
download
file View
GLI-VDLB-6-20W-5CCT-70Degree.zip
download
file View
GLI-VDLB-8-40W-5CCT-40Degree.zip
download
file View
GLI-VDLB-8-50W-5CCT-40Degree.zip
download
file View
GLI-VDLB-8-60W-5CCT-40Degree.zip
download
file View
GLI-VDLB-8-40W-5CCT-60Degree.zip
download
file View
GLI-VDLB-8-50W-5CCT-60Degree.zip
download
file View
GLI-VDLB-8-60W-5CCT-60Degree.zip
download
file View
GLI-VDLB-10-40W-5CCT-40Degree.zip
download
file View
GLI-VDLB-10-50W-5CCT-40Degree.zip
download
file View
GLI-VDLB-10-60W-5CCT-40Degree.zip
download
file View
GLI-VDLB-10-50W-5CCT-60Degree.zip
download
file View
GLI-VDLB-10-60W-5CCT-60Degree.zip
download
file View
GLI-VDLB-10-40W-5CCT-60Degree.zip
download
To add product to your project,
